Guardian® Dual Internal Auxiliary Fuel Tank System

The Guardian Dual Internal Auxiliary Fuel Tank System (IAFTS) is an internal extended-range solution for selected HH-60G, MH-60K/L/M, S-70A and S-70i helicopter configurations. Its two tanks are designed to be crashworthy and self-sealing in accordance with MIL-DTL-27422. Robertson lists cockpit-controlled transfer, cockpit fuel-quantity indication and single-point pressure refuelling as integrated operating features. Fuel may be transferred by suction or an internal pump, allowing the installation to support different mission profiles. Each tank is designed for installation or removal in approximately 15 minutes. Final fit, restraint arrangement and usable capacity depend on the approved aircraft configuration.

Key capabilities

• Dual crashworthy and self-sealing internal tanks
• Cockpit-controlled transfer with fuel-quantity indication
• Fuel transfer by suction or internal pump
• Single-point pressure refuelling
• Approximately 15-minute installation or removal per tank

Typical applications

Internal auxiliary fuel capacity for compatible H-60 and S-70 helicopter missions requiring additional endurance.

Verified specifications

• Compatible aircraft: HH-60G, MH-60K/L/M, S-70A and S-70i
• Installation time: Approximately 15 minutes per tank
• Two-tank weight with restraint: Approximately 470 lb
